Precise Rotational Rate Tracker
This ambitious project is centered on the development of an ultra-precise rotational rate tracker, capable of achieving a remarkable precision level of 0.005 degrees per second. The challenge lies in leveraging off-the-shelf, low-cost inertial measurement units (IMUs) that traditionally offer limited accuracy. By innovatively combining multiple gyroscopes and employing advanced signal processing techniques, this project aims to set a new benchmark in precision rotational tracking.
Core Components:
Triple Gyroscope Integration:
Incorporates three distinct types of gyroscopes, each contributing to a broader range of sensitivity and accuracy.
High-Precision IMUs:
Utilizes off-the-shelf IMUs, enhancing their performance through sophisticated data fusion and filtering techniques.
Data Processing and Noise Reduction:
Kalman Filter Implementation:
Fuses the signals from the three gyroscopes, employing Kalman Filters to optimize the accuracy of the rotational rate measurement.
Advanced Filtering Stages:
Includes several layers of filtering to refine the readings and reduce noise, ensuring ultra-precise output.
Signal Analysis via Fourier Transform and Frequency Spectrum Analysis:
Conducts thorough noise analysis to identify and mitigate sources of interference, further enhancing the fidelity of the measurements.
Orientation and Angle Compensation:
Mahony Filter Integration:
Fuses gyroscope and accelerometer readings using a Mahony filter, adeptly calculating Euler angles and dynamically compensating the readings based on angular changes.
Innovations and Technical Enhancements:
Precision Engineering:
Achieves an unprecedented level of precision in rotational rate measurement, pushing the boundaries of what's possible with conventional IMU technology.
Robust Signal Fusion and Analysis:
Employs state-of-the-art signal processing techniques, including Kalman and Mahony filters, to extract and refine data from multiple sensor inputs.
Comprehensive Noise Analysis:
Utilizes sophisticated methods like Fourier Transform and Frequency Spectrum Analysis to systematically identify and eliminate noise, ensuring the purity and accuracy of the data.
